Airtac HRQ Rotary Cylinder HRQ20A
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ Series Rotary Cylinder HRQ20A Technical Details
- Model: HRQ20A
- Type: Compact rack-and-pinion rotary actuator
- Bore size: 20mm
- Rotation angle: 0-190° adjustable (standard 90°±1° precision)
- Operating pressure: 0.1-0.8 MPa
- Torque output: 0.35 Nm at 0.5 MPa
- Max rotation speed: 2.0 rad/s
- Port size: M5x0.8 (dual ports for clockwise/counterclockwise)
- Mounting pattern: 4x M4 threaded holes (32mm square pattern)
- Weight: 0.48 kg
- Dimensions: 56mm(W) × 56mm(D) × 76mm(H)
- Piston seal: HNBR with wear-resistant guide rings
- Temperature range: -10℃ to 70℃
- Lubrication: Pre-lubricated (Grease-free operation)
- Shock resistance: 15m/s² (ISO 10816-3)
- Protection rating: IP54 (standard), IP67 optional
High-precision rotary actuator featuring helical gear engagement for smooth angular positioning. The hardened stainless steel shaft and dual-bearing design ensure minimal backlash (±0.2° repeatability). Optimized for cleanroom-compatible applications with <0.1mg/m³ particle emission. Requires 5μm filtered air with dew point -20℃ below ambient.
- PCB board flipping mechanisms in SMT lines
- 90° workpiece orientation changers
- Valve actuation in semiconductor wafer handling
- Camera module rotation in optical inspection systems
- Pallet indexing in pharmaceutical packaging
Installation tip:
Use dynamic alignment during mounting - maximum allowable
lateral shaft load 15N. For continuous rotation applications,
limit duty cycle to 70% with 30-second rest intervals.
| Property | Property Value |
|---|---|
| sku | HRQ20A |
| Side Port | M5×0.8 |
| Front Port | M5×0.8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Hydraulic Shock Absorber Cushioning |
| Specification | 20mm |
