Airtac HRQ Rotary Cylinder HRQ30AG
$257.52
Regular price
$265.02
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HRQ30AG
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HRQ Rotary Cylinder Technical Specifications:
1. Gear-rack mechanism ensures smooth operation;
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
Installation protocol:
Mount using M5x0.8 screws (max torque 2.5Nm). Maintain 0.5mm clearance
between mechanical stopper and actuator body. Lubricate pinion every
10,000 cycles using ISO VG32 equivalent grease.
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ Series Rotary Cylinder HRQ30AG Technical Details
- Model: HRQ30AG
- Type: Compact rotary actuator (rack and pinion design)
- Bore size: Ø30mm
- Rotation angle: 0-190° adjustable (standard 90°±5° preset)
- Torque output: 0.5-0.8 Nm (pressure-dependent)
- Operating pressure: 0.15-0.8 MPa
- Air port size: PT1/8 (G1/8 optional)
- Weight: 820g ±2%
- Dimensions: 120mm(L) × 80mm(W) × 80mm(H)
- Body material: Anodized aluminum alloy
- Seal type: HNBR/NBR (temperature-optimized variants available)
- Temperature range: -10℃ to 80℃ (extended to 120℃ with HS seals)
- Position detection: Optional magnetic sensor slot (M5 mounting)
- Rotation accuracy: ±0.5° (with adjustable stopper)
- Protection class: IP40 (IP67 with optional boot)
Precision rotary actuator featuring dual-cushion end damping and anti-backlash gear mechanism. The hardened stainless steel shaft and self-lubricating bearings ensure 500km+ service life under continuous operation. Requires filtered air (5-50μm) with ISO VG32 lubricant recommended.
Industrial Applications:
- Palletizing robot wrist articulation
- CNC machine tool automatic door actuators
- Semiconductor wafer handling indexers
- Automated packaging line product orientation
- Medical device assembly rotary fixtures
Installation protocol:
Mount using M5x0.8 screws (max torque 2.5Nm). Maintain 0.5mm clearance
between mechanical stopper and actuator body. Lubricate pinion every
10,000 cycles using ISO VG32 equivalent grease.
| Property | Property Value |
|---|---|
| sku | HRQ30AG |
| Side Port | M5×0.8 |
| Front Port | PT1/8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Hydraulic Shock Absorber Cushioning |
| Specification | 30 |
