Airtac HRQ Rotary Cylinder HRQ70
2. Dual-cylinder design enables double output force;
3. High-precision machined worktable facilitates easy load mounting and precise positioning;
4. Central through-hole allows integrated piping configuration;
5. Mounting holes provided on both sides (models 10-200) or base surface (models 2-7) for flexible installation;
6. Dual cushioning options: adjustable screw-type cushioning or hydraulic shock absorber. Hydraulic variant delivers 3-5 times greater damping energy for superior buffering performance.
*Note: HRQ2, 3, and 7 models feature screw-type cushioning only, without hydraulic shock absorber option. Category: Rotary Cylinders | Brand: AirTAC | Series: HRQ
AirTAC HRQ Series Rotary Cylinder HRQ70 Technical Specifications
- Model: HRQ70
- Type: Double-acting rotary actuator
- Bore size: 70mm
- Rotation angle: 0-190° adjustable (standard 90°±1°)
- Torque output: 50 N·m (without brake), 65 N·m (with brake)
- Operating pressure: 0.2–0.8 MPa
- Rotation speed: 0.5–2.5 sec/90° (varies with load)
- Port size: PT1/4 (G1/4 optional)
- Weight: 3.8 kg (with brake: 4.2 kg)
- Dimensions: 220mm(L) × 155mm(W) × 70mm(H)
- Body material: Anodized aluminum alloy
- Seal type: HNBR rubber (high temperature resistant)
- Temperature range: -10℃ to 120℃
- Protection class: IP40 (dust protected)
- Mounting pattern: ISO 15552 standard
High-torque rotary cylinder with precision angular positioning, featuring adjustable mechanical stoppers and optional electromagnetic brake. The hardened steel gear rack system ensures 50,000km+ service life under rated load. Integrated cushioning mechanism reduces impact at rotation endpoints by 70% compared to standard models.
- Robotic welding arm joint rotation
- Indexing table positioning in CNC machining
- 90° workpiece flipping in assembly lines
- Valve actuation in chemical processing
- Solar panel tracking systems
Installation guidelines:
Maintain 0.5mm minimum clearance between stopper screws during adjustment.
Lubricate gear teeth with ISO VG32 hydraulic oil before initial operation.
For vertical mounting, install exhaust mist separator to prevent oil drain.
| Property | Property Value |
|---|---|
| sku | HRQ70 |
| Side Port | M5×0.8 |
| Front Port | PT1/8 |
| Rotation Angle Range | 0°-190° |
| Cushion Type | Fixed Cushion |
| Specification | Bore 70 |
