Airtac HSV Hand Slide Valve HSV08SF
2、Precision-engineered directional switching mechanism with smooth sliding operation and ergonomic tactile feedback;
3、Optimized flow path design ensuring maximum Cv value;
4、Hard-anodized spool surface and anodized aluminum alloy body provide exceptional wear resistance and permanent anti-corrosion properties.
Category: Manual Slide Valve , Brand: AIRTAC , Series: HSV
AirTAC HSV Series Manual Slide Valve HSV08SF Technical Details
- Model: HSV08SF
- Type: 5/2-way manual slide valve (spring return)
- Port configuration: 5 ports (P, A, B, R, S) / 2 positions
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.05–0.9 MPa
- Max flow rate: 850 L/min (ANR)
- Actuation force: ≤25N (ergonomic thumb lever)
- Body material: Anodized aluminum alloy (black finish)
- Seal material: HNBR rubber (oil & heat resistant)
- Temperature range: -10℃ to 80℃ (with dry air)
- Weight: 320g ±5%
- Dimensions: 78mm(L) × 42mm(W) × 34mm(H)
- Mounting: ISO 15407-1 compliant sub-base (optional)
- Lubrication: Pre-lubricated (do not disassemble seals)
Industrial-grade manual override valve with tactile position feedback, featuring dual dust boots for contamination resistance. The chrome-plated stainless steel shaft and precision ground spool ensure smooth operation over 500,000 cycles. Requires ISO 8573-1 class 3.4.2 air quality (max 5μm particles).
- Emergency actuator control in production line jigs
- Manual cylinder positioning during machine maintenance
- Pneumatic system troubleshooting stations
- Educational training equipment for fluid power
- Mobile hydraulic/pneumatic hybrid systems
Maintenance tip:
Apply silicone grease (ISO 1000cSt viscosity) quarterly to the shaft
through the maintenance port. Avoid lateral force on the lever during
operation to prevent internal misalignment.
| Property | Property Value |
|---|---|
| sku | HSV08SF |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
