Airtac HSV Hand Slide Valve HSV15SF
2、Precision-engineered directional switching mechanism with smooth sliding operation and ergonomic tactile feedback;
3、Optimized flow path design ensuring maximum Cv value;
4、Hard-anodized spool surface and anodized aluminum alloy body provide exceptional wear resistance and permanent anti-corrosion properties.
Category: Manual Slide Valve , Brand: AIRTAC , Series: HSV
AirTAC HSV15SF Manual Slide Valve Technical Details
- Model: HSV15SF
- Type: 3-position (Closed Center) manual slide valve
- Port configuration: 5 ports (P, A, B, R1, R2)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 750 L/min (ANR)
- Actuation force: ≤5 N
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -20℃ to 80℃
- Weight: 235g ±5%
- Dimensions: 58mm(L) × 34mm(W) × 72mm(H)
- Mounting: Sub-base compatible (ISO 5599-1)
- Lubrication: Pre-lubricated (do not mix with petroleum-based oils)
Industrial-grade manual override valve with positive center position lock, featuring a tactile sliding mechanism with 3 distinct positions. The chrome-plated steel handle provides 360° rotational adjustment for ergonomic access. Designed for systems requiring manual intervention or emergency control in automated pneumatic circuits.
- Production line emergency stop systems
- Pneumatic cylinder manual positioning
- Machine tool clamping force adjustment
- Training simulators for fluid power education
- Maintenance bypass in automated assembly systems
Operation guidance:
Apply smooth lateral force to the T-bar handle until it clicks into position.
Avoid partial engagement - full travel ensures proper seal alignment.
Monthly cleaning with dry compressed air recommended in dusty environments.
| Property | Property Value |
|---|---|
| sku | HSV15SF |
| Position | 3-Port 2-Position |
| Port Size | PT 1/2 |
