Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM1R
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK Heavy-Duty Welding Clamping Cylinder JCK40X105AM1R Specifications
- Model: JCK40X105AM1R
- Type: Double-acting welded clamping cylinder
- Bore size: 40mm
- Stroke: 105mm
- Mounting style: Rectangular flange with reinforced ribs
- Operating pressure: 0.1–1.0 MPa
- Piston rod material: Hard chrome-plated carbon steel (JIS S45C)
- Tube material: Cold drawn precision aluminum alloy (anodized)
- Cushioning: Adjustable elastic cushion + impact absorber
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Temperature range: -20℃ to 120℃ (high-temp seals available)
- Protection rating: IP67 (wipers included)
- Weight: 2.85kg (with mounting hardware)
- Dimensions:
- Length: 242mm (full extension)
- Width: 78mm (flange base)
- Height: 53mm (body profile)
Industrial-grade clamping cylinder engineered for high stability in welding applications. Features a reinforced anti-spatter structure with copper-free aluminum construction to prevent weld contamination. The triple-sealed piston (NBR+PU+FKM) withstands particulate exposure and maintains 0.01mm repeat positioning accuracy under 500N clamping force.
- Robotic welding station fixturing
- Automotive chassis assembly jigs
- High-temperature battery module pressing
- Plasma cutting table clamping systems
- Forging die positioning mechanisms
Installation protocol:
Use M8x1.25 grade 10.9 mounting bolts with spring washers.
Apply anti-seize compound on piston rod threads when operating above 80℃.
Perform monthly purge cleaning with dry air (0.3MPa max) to remove welding debris.
| Property | Property Value |
|---|---|
| sku | JCK40X105AM1R |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 15mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
