Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM1RKA
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK40X105AM1RKA Heavy-Duty Welding Clamp Cylinder Specifications
- Model: JCK40X105AM1RKA
- Type: Double-acting welded clamp cylinder
- Bore size: 40mm (ISO 6432 standard)
- Stroke: 105mm (±0.5mm tolerance)
- Operating pressure: 0.2–1.0 MPa
- Max thrust: 1,256N @ 0.63MPa
- Temperature range: -20℃ to 100℃ (dry air required above 60℃)
- Cushioning: Adjustable hydraulic shock absorber
- Mounting type: Square flange with reinforced base (ISO 15552-MBF2)
- Port size: G1/8 (NPT1/8 optional)
- Rod material: Hard chrome-plated steel (5-8μm coating)
- Tube material: Anodized aluminum alloy (16MPa burst pressure rating)
- Seal material: Heat-resistant NBR + PU combination
- Weight: 2.8kg (without accessories)
- Dimensions: 278mm(L) × 68mm(W) × 68mm(H) (full extension)
- Protection rating: IP67 (wipers included)
- Repeat accuracy: ±0.1mm
Industrial-grade welding clamp cylinder engineered for high rigidity and deformation resistance in high-temperature environments. Features triple-sealed construction with anti-spatter coating (3μm thickness) to withstand welding debris. Integrated guide rods provide 20% higher side load capacity than standard cylinders. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Robotic welding fixture systems (automotive body shops)
- Forging press mold clamping
- High-frequency induction heating workholding
- Plastic injection mold carrier positioning
- Battery pack assembly line compression
Operation note:
Apply high-temperature grease (NLGI #2, 180℃ rating) to rod surface every 50,000 cycles.
Use 2-point symmetrical clamping force calculation: F=0.25πD²P×μ (μ=0.8-1.2 based on pad material).
| Property | Property Value |
|---|---|
| sku | JCK40X105AM1RKA |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 15mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
