Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM3LK
$283.78
Regular price
$291.28
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
JCK40X105AM3LK
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
JCK Heavy-duty Welding Clamp Cylinder
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
Installation note:
Requires minimum 0.5mm radial clearance around rod during alignment.
Use locknut tightening torque of 35-40N·m. For continuous duty cycles above 60 CPM,
install external guide mechanism (sold separately).
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK40X105AM3LK Heavy-Duty Welding Clamp Cylinder Specifications
- Model: JCK40X105AM3LK
- Type: Double-acting welded rod clamping cylinder
- Bore size: 40mm
- Stroke: 105mm
- Operating pressure: 0.1–1.0 MPa
- Operating medium: Dry air (ISO8573-1:2010 Class 3.4.2)
- Ambient temperature: -20℃ to 80℃ (non-freezing)
- Piston speed: 50–800 mm/s
- Rod end thread: M16×1.5 (ISO 228-1 G1/2 optional)
- Buffer type: Adjustable rubber cushion (both ends)
- Mounting type: AM3 series flange mounting
- Material:
- Tube: Aluminum alloy hard anodized
- Piston rod: Chrome-plated 45# steel
- Seals: HNBR (high nitrile) with wear-resistant ring
- Weight: 2.8 kg (with standard accessories)
- Dimensions:
- Extended length: 260mm
- Retracted length: 155mm
- Body diameter: 50mm ±0.5
- Mounting flange: 75mm × 75mm square base
- Protection rating: IP65 (rod extension area IP54)
- Lubrication: Pre-lubricated (DOP mist compatible)
Industrial-grade clamping cylinder with reinforced weld structure, designed for high shock load applications. Features precision ground rod and anti-rotation mechanism for stable positioning. Integrated impact absorption system reduces vibration during sudden stops by 40% compared to standard models.
Typical Applications:
- Robotic welding fixture systems
- Automotive chassis component jigs
- Heavy plate pressing operations
- Foundry mold clamping devices
- CNC machine tool workpiece locking
Installation note:
Requires minimum 0.5mm radial clearance around rod during alignment.
Use locknut tightening torque of 35-40N·m. For continuous duty cycles above 60 CPM,
install external guide mechanism (sold separately).
| Property | Property Value |
|---|---|
| sku | JCK40X105AM3LK |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 45mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
