Airtac JCK High Strength Welding Clamping Cylinder JCK40X105K
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK Series Heavy-Duty Welding Clamp Cylinder JCK40X105K Specifications
- Model: JCK40X105K
- Bore size: 40mm
- Stroke: 105mm
- Operating pressure: 0.1–1.0 MPa
- Temperature range: -10℃ to 150℃ (peak resistance)
- Cushioning: Adjustable elastic cushion + shock absorber
- Mounting style: Fixed type (front flange)
- Port size: G1/8 (NPT1/8 optional)
- Rod end: Female thread M16×1.5
- Body material: Anodized aluminum alloy (ISO AlMg3)
- Seal material: Heat-resistant NBR + special wear ring
- Protection rating: IP67 (w/ dust cover)
- Weight: 2.65 kg ±3%
- Dimensions: 216mm(L) × 58mm(W) × 58mm(H) (retracted state)
- Max thrust: 503N @ 0.63MPa
- Repeat accuracy: ±0.5mm
Robust welding-grade cylinder with enhanced heat deflection resistance, featuring a reinforced rod lock mechanism for vibration-intensive environments. The triple-sealed construction prevents spatter ingress, with chromium-plated piston rod (15μm thickness) for anti-corrosion. Requires 5-40μm filtered air with lubrication (ISO VG32 recommended).
- Robotic welding fixture positioning
- Automotive chassis component clamping
- Foundry mold locking systems
- Heavy plate press alignment
- Forging machine tool retention
Installation protocol:
Apply thermal barrier paste on mounting surfaces when ambient temperature exceeds 80℃.
Perform bi-weekly purge cleaning in high-spatter environments.
Torque mounting bolts to 22-25N·m using cross pattern sequence.
| Property | Property Value |
|---|---|
| sku | JCK40X105K |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Without Clamping Arm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
