Airtac JSI Series Standard Cylinder JSI100X1000FA
2. Features profiled bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. JSI Series utilizes cross-braced aluminum alloy tubing with tie-rod-free design, offering superior corrosion resistance;
4. Reduced overall length compared to ISO15552 standard cylinders of equivalent bore size;
5. Precision-adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive selection of bore sizes and mounting accessories available for customized system integration.
Category: Standard Cylinders, Brand: AirTAC, Series: JSI
AirTAC JSI Standard Cylinder JSI100X1000FA Technical Specifications
- Model: JSI100X1000FA
- Type: ISO 15552 compliant double-acting cylinder
- Bore size: Ø100 mm
- Stroke: 1000 mm (customizable 25-2000mm)
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Front flange (FA series) with ISO 15552 mounting pattern
- Port size: G1/2 (BSPP thread)
- Piston rod material: Hard chrome-plated steel (Ø25mm)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile) standard, optional FKM/Viton
- Temperature range: -20℃ to +80℃
- Weight: 21.5 kg (dry, without accessories)
- Dimensions: 1165mm(L) × 155mm(W) × 155mm(H)
- Max thrust: 7060N @0.63MPa (push/pull)
- Speed range: 50-1000 mm/s
- Protection rating: IP65 (standard), IP67 optional
- Position sensing: Magnetizable for sensor mounting
Heavy-duty industrial cylinder designed for high-force linear motion applications. Features precision honed tube with wear-resistant coating and dual anti-rotation guides for stable long-stroke operation. Integrated cushioning adjustment screws allow fine-tuning of end-position deceleration. Compatible with all ISO 15552 mounting accessories.
- Automotive assembly line clamping fixtures
- Steel mill material handling systems
- Plastic injection molding machine ejectors
- Paper processing equipment actuators
- Heavy press brake tool positioning
Installation guidelines:
Requires rigid mounting surface with flatness ≤0.1mm/m. For horizontal strokes >800mm,
recommend using intermediate rod support (ASMU-100 accessory). Lubricate with ISO VG32
hydraulic oil through built-in lubrication ports before initial operation.
| Property | Property Value |
|---|---|
| sku | JSI100X1000FA |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
