Airtac JSI Series Standard Cylinder JSI100X125H
$175.16
Regular price
$182.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
JSI100X125H
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. JIS-compliant triple-seal cylinder;
2. Features profiled bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. JSI Series utilizes cross-braced aluminum alloy tubing with tie-rod-free design, offering superior corrosion resistance;
4. Reduced overall length compared to ISO15552 standard cylinders of equivalent bore size;
5. Precision-adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive selection of bore sizes and mounting accessories available for customized system integration.
Category: Standard Cylinders, Brand: AirTAC, Series: JSI
Installation tip:
Maintain 0.1–0.3mm clearance between rod end and load during alignment.
Use locknuts with 35–45 N·m torque specification. Lubricate weekly under continuous operation.
2. Features profiled bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. JSI Series utilizes cross-braced aluminum alloy tubing with tie-rod-free design, offering superior corrosion resistance;
4. Reduced overall length compared to ISO15552 standard cylinders of equivalent bore size;
5. Precision-adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive selection of bore sizes and mounting accessories available for customized system integration.
Category: Standard Cylinders, Brand: AirTAC, Series: JSI
AirTAC JSI Standard Cylinder JSI100X125H Technical Details
- Model: JSI100X125H
- Type: ISO 6432 compliant single-acting spring return cylinder
- Bore size: 100mm (±0.1mm tolerance)
- Stroke: 125mm (adjustable cushioning)
- Operating pressure: 0.05–1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning type: Rubber buffer + adjustable hydraulic absorber
- Mounting style: Square ISO pattern with 4x M8 threaded holes
- Port size: G3/8 (BSPP thread)
- Piston rod thread: M20×1.5 external thread
- Material:
- Cylinder tube: Aluminum alloy hard anodized
- Piston rod: Chrome-plated steel (Cr-Mo)
- Seals: NBR (standard), optional FKM for high temp
- Weight: 5.8kg (without accessories)
- Dimensions:
- Total length: 225mm (at full retraction)
- Stroke length: 125mm
- Outer diameter: 100mm
- Mounting height: 120mm
High-force industrial cylinder featuring dual cushioning system and corrosion-resistant construction. The H-suffix model includes enhanced rod bearing for side load resistance. Requires ISO VG32 hydraulic oil lubrication for optimal performance. Maximum piston speed: 0.1–1.5 m/s.
Industrial Applications:
- Plastic injection molding machine ejectors
- Heavy-duty material handling systems
- Automotive assembly line positioning
- Paper processing equipment actuators
- Foundry machine door clamping
Installation tip:
Maintain 0.1–0.3mm clearance between rod end and load during alignment.
Use locknuts with 35–45 N·m torque specification. Lubricate weekly under continuous operation.
| Property | Property Value |
|---|---|
| sku | JSI100X125H |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 125mm |
