Airtac JSI Series Standard Cylinder JSI100X125STC
2. Features profiled bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. JSI Series utilizes cross-braced aluminum alloy tubing with tie-rod-free design, offering superior corrosion resistance;
4. Reduced overall length compared to ISO15552 standard cylinders of equivalent bore size;
5. Precision-adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive selection of bore sizes and mounting accessories available for customized system integration.
Category: Standard Cylinders, Brand: AirTAC, Series: JSI
AirTAC JSI100X125STC Standard Cylinder Specifications
- Model: JSI100X125STC
- Type: ISO 6432 compliant double-acting cylinder with magnetic piston
- Bore size: Ø100mm
- Stroke: 125mm (customizable 25-500mm)
- Operating pressure: 0.05–1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable air cushion at both ends
- Port size: G3/8 (NPT1/2 optional)
- Piston rod thread: M20×1.5
- Seal material: NBR (Nitrile rubber)
- Mounting type: STC (Fixed type front flange with threaded mounting holes)
- Weight: 6.8kg (without rod end accessories)
- Dimensions:
- Body length: 228mm
- Total extended length: 353mm (228+125)
- Width (flange): 150mm
- Height (with rod): 182mm
- Protection rating: IP65 (wipers included)
- Lubrication: Pre-lubricated (Use ISO VG32 hydraulic oil if relubrication needed)
Heavy-duty industrial cylinder featuring precision honed tube and chrome-plated piston rod (hardness HRC45-55). The STC mounting configuration provides stable fixed-point installation for high moment load applications. Integrated magnetic piston enables position feedback when used with compatible sensors (sold separately).
- Press machine ejection systems
- Automated foundry equipment
- Plastic injection molding clamp mechanisms
- Heavy conveyor gate controls
- Paper processing machinery
Installation guidelines:
- Align cylinder axis within 0.2mm parallel tolerance
- Use locknuts with 25-30Nm torque for rod-end connections
- Maintain 0.5-1mm clearance between magnetic sensor and cylinder body
- Install after-filter regulator when using non-lubricated air
| Property | Property Value |
|---|---|
| sku | JSI100X125STC |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 125mm |
