Airtac JSID Double Rod Cylinder JSID100X225S
2、Patented profiled bidirectional sealing configuration with compact dimensions and integrated oil reservoir functionality;
3、Honeycomb-reinforced aluminum tubing structure (JSI series) features rodless construction and enhanced corrosion resistance;
4、Compact stroke length compared to ISO15552 standard cylinders with equivalent bore sizes;
5、Precision-engineered smooth cushioning adjustment mechanism;
6、Comprehensive selection of cylinder specifications and mounting accessories for flexible system integration.
Category: Dual-axis Cylinder , Brand: AirTAC , Series: JSID
AirTAC JSID100X225S Double Rod Cylinder Technical Details
- Series: JSID Dual Axis Industrial Cylinder
- Bore size: Ø100mm
- Stroke: 225mm (adjustable stroke available)
- Operation: Double acting (air cushion both ends)
- Working pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Port size: G1/2 (NPT1/2 optional)
- Rod diameter: Ø25mm (both rods)
- Buffer type: Fixed cushion with adjustable shock absorber
- Seal material: HNBR (Hydrogenated Nitrile) + PU
- Mounting style: Basic type (MF1) with front flange
- Weight: 12.8 kg (dry, without accessories)
- Dimensions:
- Length: 540mm (including rods)
- Body width: 128mm
- Height: 128mm
- Stroke tolerance: ±1.5mm
High-rigidity dual piston rod cylinder engineered for precision linear motion in heavy-duty applications. Features symmetrical force transmission through parallel rods, reducing lateral deflection by 60% compared to single rod models. Integrated shock absorption system minimizes end-impact noise below 75dB. Corrosion-resistant anodized aluminum body with chrome-plated steel rods withstands harsh industrial environments.
- Automated palletizing systems requiring dual-sided force output
- Press machine tooling with precise parallel motion requirements
- Automotive welding fixtures needing vibration resistance
- Heavy material clamping devices
- CNC machine tool chip conveyors
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting.
Apply ISO VG32 hydraulic oil for initial lubrication.
Avoid side load exceeding 150N.
Recommend using with AR-12 rod lock for vertical installations.
| Property | Property Value |
|---|---|
| sku | JSID100X225S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 225mm |
