Airtac JSID Double Rod Cylinder JSID100X25S
2、Patented profiled bidirectional sealing configuration with compact dimensions and integrated oil reservoir functionality;
3、Honeycomb-reinforced aluminum tubing structure (JSI series) features rodless construction and enhanced corrosion resistance;
4、Compact stroke length compared to ISO15552 standard cylinders with equivalent bore sizes;
5、Precision-engineered smooth cushioning adjustment mechanism;
6、Comprehensive selection of cylinder specifications and mounting accessories for flexible system integration.
Category: Dual-axis Cylinder , Brand: AirTAC , Series: JSID
AirTAC JSID Double Rod Cylinder JSID100X25S Technical Details
- Model: JSID100X25S
- Type: Double rod, double-acting cylinder
- Bore size: 100mm
- Stroke: 25mm
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-700 mm/s
- Port size: G3/8 (NPT1/2 optional)
- Cushioning: Adjustable rubber buffer (both ends)
- Operating temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Rod material: Hard chrome-plated steel
- Protection rating: IP54 (standard), IP67 (optional w/wiper)
- Weight: 3.8 kg (excluding accessories)
- Dimensions:
- Body length: 214mm
- Overall width: 148mm (mounting bracket included)
- Height: 132mm
- Rod diameter: 25mm (per rod)
High-rigidity dual rod cylinder with integrated guide rails, designed for precision linear motion requiring exceptional moment resistance. Features twin chromium-plated piston rods with anti-rotation design and precision ground tube interior. Includes magnetic piston for position sensing compatibility (sensors sold separately). Requires 40μm filtered lubricated air (ISO 8573-1 class 4).
- Automated material handling systems
- Precision press tooling operations
- Glass cutting machinery positioning
- Semiconductor wafer handling robots
- Vertical lifting mechanisms in packaging lines
Mounting advice:
For optimal performance in high-side load applications, use with
linear guide blocks (LG series recommended) and maintain perpendicular alignment
within 0.2mm/m tolerance. Lubricate through air supply (ISO VG32 pneumatic oil).
| Property | Property Value |
|---|---|
| sku | JSID100X25S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | <25 mm> |
