Airtac JSID Double Rod Cylinder JSID100X350S
2、Patented profiled bidirectional sealing configuration with compact dimensions and integrated oil reservoir functionality;
3、Honeycomb-reinforced aluminum tubing structure (JSI series) features rodless construction and enhanced corrosion resistance;
4、Compact stroke length compared to ISO15552 standard cylinders with equivalent bore sizes;
5、Precision-engineered smooth cushioning adjustment mechanism;
6、Comprehensive selection of cylinder specifications and mounting accessories for flexible system integration.
Category: Dual-axis Cylinder , Brand: AirTAC , Series: JSID
AirTAC JSID100X350S Double Rod Cylinder Specifications
- Model: JSID100X350S
- Type: Double rod compact cylinder (ISO 6432 standard)
- Bore size: Ø100 mm
- Stroke: 350 mm (adjustable stroke version available)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning type: Fixed rubber buffer + adjustable cushion
- Port size: G3/8 (NPT1/2 optional)
- Rod diameter: Ø25 mm (both rods)
- Rod material: Hard chrome-plated steel
- Seal material: NBR + PU combination
- Weight: 12.8 kg (dry, without accessories)
- Dimensions:
- Length: 725 mm (full extension)
- Body width: 120 mm
- Height: 140 mm (including mounting brackets)
- Mounting types: MF1 (front flange), MB1 (rear pivot)
- Protection rating: IP67 (standard wiper design)
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil)
High-rigidity dual rod cylinder with symmetrical force output, featuring precision ground rods and anti-rotation design. The twin piston rod configuration minimizes lateral load deflection, making it ideal for precision alignment tasks. Includes magnetic piston for position sensing compatibility (sensor not included).
- Precision press mechanisms in automotive welding lines
- Vertical lifting platforms for material handling
- Clamping fixtures for CNC machining centers
- Paper feed systems in printing machinery
- Glass panel transfer systems
Installation note:
Maintain parallel alignment of both rods during assembly.
For horizontal mounting, use central support brackets when stroke exceeds 300mm.
Lubricate rod surfaces weekly in high-cycle applications (>500 cycles/min).
| Property | Property Value |
|---|---|
| sku | JSID100X350S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 350mm |
