Airtac JSID Double Rod Cylinder JSID100X400S
2、Patented profiled bidirectional sealing configuration with compact dimensions and integrated oil reservoir functionality;
3、Honeycomb-reinforced aluminum tubing structure (JSI series) features rodless construction and enhanced corrosion resistance;
4、Compact stroke length compared to ISO15552 standard cylinders with equivalent bore sizes;
5、Precision-engineered smooth cushioning adjustment mechanism;
6、Comprehensive selection of cylinder specifications and mounting accessories for flexible system integration.
Category: Dual-axis Cylinder , Brand: AirTAC , Series: JSID
AirTAC JSID Dual Rod Cylinder JSID100X400S Technical Details
- Model: JSID100X400S
- Type: ISO 15552 compliant dual-rod cylinder
- Bore size: Ø100 mm
- Stroke: 400 mm (adjustable cushion)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Rod material: Hard chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal type: HNBR wiper + NBR main seals
- Mounting style: Basic (NFAC series brackets optional)
- Cushioning: Adjustable air cushion (both ends)
- Weight: 6.8 kg (dry, without accessories)
- Dimensions: 560mm(L) × 150mm(W) × 120mm(H)
- Port size: G3/8 (NPT1/2 optional)
- Repeat positioning accuracy: ±0.5 mm
- Max lateral load: 850N at rod end
High-rigidity dual rod cylinder designed for precision linear motion requiring exceptional moment resistance. Features symmetrical force distribution through parallel guide rods, with integrated shock absorbers preventing end-stroke vibration. Compatible with magnetic sensors (SM/SD series) for position feedback. Requires ISO VG32 hydraulic oil mist lubrication in continuous operation.
- Automated palletizing systems (vertical axis)
- Press machine ejection mechanisms
- Glass handling vacuum plate manipulators
- Plastic injection mold core-pulling units
- Automotive welding fixture positioning
Installation guidelines:
Ensure perfect parallelism (≤0.2mm/m) between guide rods and load path.
Use alignment couplers (MC series) when connecting to driven components.
Lubricate rod surfaces weekly with ISO VG68 oil in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | JSID100X400S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | <400mm> |
