Airtac JSID Double Rod Cylinder JSID100X450S
2、Patented profiled bidirectional sealing configuration with compact dimensions and integrated oil reservoir functionality;
3、Honeycomb-reinforced aluminum tubing structure (JSI series) features rodless construction and enhanced corrosion resistance;
4、Compact stroke length compared to ISO15552 standard cylinders with equivalent bore sizes;
5、Precision-engineered smooth cushioning adjustment mechanism;
6、Comprehensive selection of cylinder specifications and mounting accessories for flexible system integration.
Category: Dual-axis Cylinder , Brand: AirTAC , Series: JSID
AirTAC JSID100X450S Twin Rod Cylinder Specifications
- Model: JSID100X450S
- Type: Double rod ISO cylinder (twin piston rod design)
- Bore size: Ø100mm
- Stroke: 450mm (customizable 25-2000mm)
- Operating pressure: 0.05–1.0 MPa
- Operating medium: Dry air (lubricated or non-lubricated)
- Cushioning: Adjustable air cushion (both ends)
- Mounting: Basic type (optional foot/mounting flange)
- Rod type: Hard chrome-plated steel rods (dual rods)
- Port size: Rc1/4 (G1/4 optional)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy body (anodized), NBR seals
- Weight: 12.8kg (excluding mounting accessories)
- Dimensions: 672mm(L) × 128mm(W) × 128mm(H) (full extension)
- Rod diameter: Ø25mm (per rod)
- Max theoretical force: 785N @ 0.7MPa
- Piston speed: 50–700mm/s
High-rigidity twin rod cylinder designed for precision linear motion requiring balanced force distribution. Features dual chrome-plated rods for enhanced stability under heavy moment loads, with corrosion-resistant construction and adjustable pneumatic cushions. Includes built-in magnet for position sensing compatibility.
- Automated machinery requiring symmetrical force output
- Packaging equipment clamping mechanisms
- Precision press tooling operations
- Material handling transfer systems
- Electronic component assembly fixtures
- Automotive part positioning devices
Installation notes:
- Align within 0.2mm/m perpendicularity tolerance during mounting
- Use flexible couplings when connecting to guided mechanisms
- Maintain 1.5mm minimum clearance between rods in parallel setups
- Apply ISO VG32 hydraulic oil if using non-lubricated air
Critical parameters:
- Max side load: 490N (per rod)
- Lubrication interval: 3 months (continuous operation)
- Do NOT exceed 1.5MPa test pressure
- Ambient humidity must remain below 90% RH
| Property | Property Value |
|---|---|
| sku | JSID100X450S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 450mm |
