Airtac JSID Double Rod Cylinder JSID100X50
2、Patented profiled bidirectional sealing configuration with compact dimensions and integrated oil reservoir functionality;
3、Honeycomb-reinforced aluminum tubing structure (JSI series) features rodless construction and enhanced corrosion resistance;
4、Compact stroke length compared to ISO15552 standard cylinders with equivalent bore sizes;
5、Precision-engineered smooth cushioning adjustment mechanism;
6、Comprehensive selection of cylinder specifications and mounting accessories for flexible system integration.
Category: Dual-axis Cylinder , Brand: AirTAC , Series: JSID
AirTAC JSID Series Dual Rod Cylinder JSID100X50 Technical Specifications
- Model: JSID100X50
- Bore size: Ø100 mm
- Stroke: 50 mm
- Operating pressure: 0.05-1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable pneumatic cushion (both ends)
- Mounting style: Basic type (MF1) with fixed mounting holes
- Port size: G3/8 (NPT1/2 optional)
- Piston rod thread: M16×1.5 (dual symmetrical rods)
- Cylinder material: Aluminum alloy with hard anodized surface
- Seal material: NBR (Nitrile Butadiene Rubber)
- Protection rating: IP40 (standard dust protection)
- Weight: 3.8 kg (±5%)
- Dimensions: 200mm(L) × 100mm(W) × 120mm(H) (excluding rods)
- Rod diameter: Ø20mm (per rod)
- Max theoretical thrust: 785N @0.8MPa
- Lubrication: Pre-lubricated (recommended ISO VG32 oil mist lubrication)
High-rigidity dual rod cylinder designed for precision linear motion applications requiring enhanced moment resistance. Features symmetrical load distribution through parallel rods and reinforced end caps. The twin-rod configuration minimizes rotational deflection during operation, making it ideal for precise positioning tasks.
- Precision clamping fixtures in CNC machining centers
- Vertical lifting mechanisms in material handling systems
- Positioning stages in semiconductor manufacturing
- Press-fit operations in automotive assembly lines
- Guiding mechanisms for heavy-duty linear slides
Installation Guidelines:
Maintain 0.5mm minimum clearance between rods during alignment. Use precision leveling tools during mounting.
For vertical installations, install air vents upward. Lubricate through air supply (ISO VG32 oil mist at 1:3000 ratio).
| Property | Property Value |
|---|---|
| sku | JSID100X50 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | <50mm> |
