Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X100-30S
2. Features profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3. JSI series adopts aluminum tube with internal cross rib reinforcement (rodless design), offering enhanced corrosion resistance;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5. Smooth cushioning adjustment mechanism for stable operation;
6. Available in multiple configurations with comprehensive cylinder mounting accessories.
Category: Standard Cylinders | Brand: AIRTAC | Series: JSIJ100~125
AirTAC JSIJ100~125 Adjustable Cylinder JSIJ100X100-30S Specifications
- Model Series: JSIJ100~125 (Specific model: JSIJ100X100-30S)
- Type: Double-acting adjustable stroke cylinder
- Bore size: 100mm
- Stroke: 100mm (±5mm adjustable)
- Adjustment range: ±5mm via mechanical stopper
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Standard ISO/VDS bracket mounting
- Port size: G1/8 (Rc1/8 optional)
- Temperature range: -20℃ to 80℃
- Body material: Aluminum alloy (anodized)
- Piston rod: Chrome-plated steel (Cr-Mo alloy)
- Seal material: NBR (Nitrile rubber)
- Weight: 2.8kg (with mounting brackets)
- Dimensions:
- Extended length: 260mm (at max stroke)
- Retracted length: 160mm
- Body diameter: 100mm (cylindrical section)
- Mounting base: 125mm × 50mm
Heavy-duty adjustable stroke cylinder with precision positioning capability, featuring a dual-locking mechanism for stroke adjustment. The chrome-plated piston rod and integrated wear rings ensure smooth operation in high-cycle applications. Includes magnetic piston for sensor compatibility and shock-absorbing bumpers for impact reduction.
- Press machine stroke control systems
- Automated assembly line positioning devices
- Packaging machine product height adjustment
- Die-casting machine ejection mechanisms
- Automotive welding fixture positioning
Installation note:
Requires minimum 0.5mm alignment tolerance during mounting.
Lubricate with ISO VG32 hydraulic oil before initial operation.
For vertical installations, use auxiliary guide mechanisms when
handling side loads exceeding 50N.
- Re-lubrication interval: Every 500km of cumulative stroke
- Seal replacement cycle: 5,000 operating hours
- Air filtration requirement: 5μm minimum with auto-drain
| Property | Property Value |
|---|---|
| sku | JSIJ100X100-30S |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 100mm |
