Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-10
The AirTAC Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-10 is a genuine double acting, adjustable stroke JIS-standard air cylinder with a Ø100mm bore and 1000mm stroke, G1/2 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ100 mm
- Stroke1000 mm
- Port sizeG1/2
- Acting typeDouble acting, adjustable stroke
- Rod threadM26×1.5
- CushionAdjustable, 33 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-10
Generating 3927 N of push force at 0.5 MPa, this 100 mm bore JIS profile cylinder brings heavy-duty actuation into a footprint notably shorter than a same-bore ISO 15552 unit. The hard-anodized aluminum extruded barrel houses a 32 mm rod and uses a G1/2 port.
An external stop screw provides a 10 mm on-site extend-shortening window, letting you fine-tune the end position between 990 and 1000 mm without swapping the actuator. In practical terms it handles about 2356 N of real work safely, lifting roughly 200 kg vertically with a 2:1 margin. Note this plain SKU lacks a magnet and cannot take CMSE/DMSE sensors.
Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-10 Technical Specifications
| Model | Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-10 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø100 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/2 |
| Rod thread | M26×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 33 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3525 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-10
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 100 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-10 Is Used
Press Tonnage Trimming
Dial in the exact 990 to 1000 mm extend stop on-site to set precise press contact depth without machining new spacers.
Long-Reach Diversion
Pushes heavy pallets along a transfer line, using the compact JIS profile to save valuable machine length.
Vertical Lift Gates
Lifts roughly 200 kg vertical loads safely, with the external adjuster allowing quick timing synchronization of dual gates.
Is the Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-10 the Right Cylinder?
For lighter cycles the 80 mm bore yields 2513 N push at 0.5 MPa, while the 125 mm bore steps up to 6136 N if you need more thrust. The 10 mm adjuster is ideal for sharing a spare across stroke variants or finalizing end positions on-site. Mounting options include FA, LB, TC, TCM1, and TCM2. Because the stroke is 1000 mm, always use an external guide to prevent rod bending and manage side loads. Remember this no-magnet SKU cannot support position sensing.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-10 FAQ
At 0.5 MPa it pushes 3927 N and pulls 3574 N. At 0.7 MPa push is 5497 N and pull is 5003 N. The theoretical max force is 801 kgf at 1.0 MPa. It uses a G1/2 port, a 32 mm rod with an M26x1.5 thread, and has 33 mm adjustable air cushions at both ends.
The external stop screw lets you shorten the extend stroke by up to 10 mm on-site, giving a usable range of 990 to 1000 mm. The nominal 1000 mm stroke is the maximum. The retract end is fixed. This mechanism only sets the end position; it does not lock the load, so use an external rod lock or pilot-operated check valve for holding.
