Airtac JSIJ100~125 Adjustable Cylinder JSIJ100X1000-50
2. Features profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3. JSI series adopts aluminum tube with internal cross rib reinforcement (rodless design), offering enhanced corrosion resistance;
4. Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5. Smooth cushioning adjustment mechanism for stable operation;
6. Available in multiple configurations with comprehensive cylinder mounting accessories.
Category: Standard Cylinders | Brand: AIRTAC | Series: JSIJ100~125
AirTAC JSIJ100X1000-50 Adjustable Cylinder Specifications
- Series: JSIJ100~125 Adjustable Cylinder Series
- Model Code: JSIJ100X1000-50
- Bore Size: 100mm (3.94")
- Stroke: 1000mm (39.37")
- Operating Pressure: 0.15-0.8 MPa (21.7-116 psi)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Cushion Type: Adjustable Air Cushion (Both Ends)
- Mounting Style: Basic Type (MF1: Front Flange / MF2: Rear Flange / MB1: Foot Mount)
- Port Size: 1/2" NPT or G1/2 (Optional)
- Piston Rod Material: Hard Chrome-plated Steel (HRC 35-42)
- Tube Material: Anodized Aluminum Alloy
- Seal Material: NBR + Polyurethane Combination
- Stroke Adjustment Range: ±5mm at Both Ends
- Repeat Positioning Accuracy: ±0.5mm
- Max. Piston Speed: 500-700 mm/s (Lubricated)
- Lubrication Requirement: ISO VG32 Turbine Oil (Optional Oil-less)
- Protection Rating: IP65 (Dust Tight & Water Jet Protected)
- Weight: 15.8 kg (34.8 lbs) ±3%
- Dimensions (L×W×H): 1165mm × 125mm × 125mm (45.87" × 4.92" × 4.92")
High-precision long-stroke cylinder with dual adjustable pneumatic cushions, designed for heavy-duty industrial applications requiring controlled deceleration. Features wear-resistant chromium plating and multi-layered sealing system (primary NBR + secondary PU seals). Optional magnetic piston version (JSIJ100X1000-50/M) enables position feedback when paired with proximity sensors.
- Automated palletizing systems in logistics centers
- Press machine ejection mechanisms
- Automotive welding fixture positioning
- Large-format CNC router tool changers
- Paper converting equipment actuators
Installation Guidelines:1. Maintain 0.5mm minimum clearance between rod end and load during alignment
2. Use flexible couplings for stroke >500mm applications
3. For vertical mounting: Add 10-15% extra thrust capacity margin
4. Cushion adjustment: Turn clockwise to increase damping (1 rotation ≈ 20% force change)
| Property | Property Value |
|---|---|
| sku | JSIJ100X1000-50 |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
