Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-100S
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
AirTAC JSIJ32X100-100S Adjustable Cylinder Specifications
- Series: JSIJ32~50 Adjustable Stroke Series
- Model: JSIJ32X100-100S
- Bore size: 32mm
- Stroke: 100mm (Adjustable range: 50-100mm)
- Operating pressure: 0.1~0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable air cushion
- Rod material: Stainless steel (SUS304)
- Tube material: Aluminum alloy (hard anodized)
- Port size: 1/8" NPT (M5 optional)
- Mounting type: Basic type (axial mounting)
- Weight: 1.25kg ±5%
- Dimensions: 200mm(L) × 40mm(W) × 40mm(H) (at full extension)
- Piston speed: 50-800mm/s
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP54 (standard wiper design)
Precision adjustable stroke cylinder with dual-position locking mechanism, featuring micrometer-style stroke adjustment (±0.5mm repeatability). The 3-stage anodized barrel provides enhanced wear resistance, while the magnetic piston enables position feedback when used with sensors. Includes built-in shock absorbers at both ends for high-speed operation up to 0.8m/s.
- CNC machine tool clamping mechanisms
- Automated packaging line positioning
- Semiconductor wafer handling robots
- Printing press paper feed systems
- Automotive assembly jig positioning
Installation notes:
- Always lock adjustment screws with 1.2N·m torque after positioning
- Use ISO VG32 hydraulic oil for lubrication (prohibited in food applications)
- Maintain 0.3mm minimum clearance between magnetic sensor and cylinder body
- Avoid side loads exceeding 15N during operation
| Property | Property Value |
|---|---|
| sku | JSIJ32X100-100S |
| Adjustable Stroke | 100mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | <20mm> |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
