Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-40
$65.36
Regular price
$72.86
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
JSIJ32X125-40
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、JIS Standard Cylinder;
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maximum side load tolerance reduces by 30% when stroke is adjusted below 50%.
Recommend using AR-12 rod locknut for vibration-prone applications.
2、Features specially-shaped bidirectional sealing structure with integrated oil reservoir for compact piston sealing design;
3、JSI series adopts tie-rod-free construction with H-shaped aluminum tube for enhanced corrosion resistance;
4、Compact length compared to ISO15552 standard cylinders of equivalent bore size;
5、Precision-engineered cushioning adjustment ensures smooth stroke termination;
6、Comprehensive selection of cylinder specifications and mounting accessories available for customized solutions.
Category: Standard Cylinders , Brand: AIRTAC , Series: JSIJ32~50
AirTAC JSIJ32X125-40 Adjustable Stroke Cylinder Specifications
- Series: JSIJ32~50 (32mm/40mm/50mm bore sizes)
- Full model: JSIJ32X125-40
- Bore size: 32mm
- Stroke: 125mm (adjustable through external stopper)
- Operating pressure: 0.05–0.9 MPa
- Medium temperature: -20℃ to 80℃
- Buffer type: Fixed rubber cushion + adjustable stopper
- Mounting style: AX-type (front flange with rear support)
- Port size: M5x0.8 (G1/8 equivalent flow)
- Piston rod thread: M10x1.25
- Material: Aluminum alloy barrel, CR12MoV chrome-plated rod
- Seals: NBR/Urethane compound
- Weight: 0.82kg (without accessories)
- Dimensions: 155mm(L) × 52mm(W) × 52mm(H) (minimum retracted length)
- Max lateral load capacity: 25N at full extension
- ISO standard: 6432
Compact adjustable stroke cylinder featuring dual-position locking mechanism with ±1mm repeatability. The external stroke adjustment screw enables 0-100% stroke modification without disassembly. Nickel-plated end covers prevent corrosion in humid environments.
Industrial Applications:
- Precision workpiece clamping in CNC fixture systems
- Conveyor gate positioning in packaging lines
- Height adjustment mechanisms in automated test equipment
- Sheet metal bending machine stroke control
- Robotic tool changer positioning
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maximum side load tolerance reduces by 30% when stroke is adjusted below 50%.
Recommend using AR-12 rod locknut for vibration-prone applications.
Accessory Pairing:
- Use ASNU-32 mounting brackets for vertical installations
- Pair with JSCA32 auto switch for position feedback
- Optimal speed control: 50-500mm/s using ASC-200 flow control valve
| Property | Property Value |
|---|---|
| sku | JSIJ32X125-40 |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Stroke | <20mm> |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
