Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100S
The AirTAC JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100S is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø63mm bore and 1000mm stroke, G3/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ63 mm
- Stroke1000 mm
- Port sizeG3/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM18×1.5
- CushionAdjustable, 29 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100S
The hard-anodized aluminum extruded barrel makes it shorter and more compact than a same-bore ISO 15552 unit.
A built-in magnet (-S) allows CMSE or DMSE sensors to drop directly into the side grooves. The external adjuster lets you shorten the extend stroke on-site by up to 100 mm, giving a usable range of 900 to 1000 mm while the retract end stays fixed. Air connects via a G3/8 port, and adjustable air cushions of 29 mm decelerate the piston at both ends.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100S Technical Specifications
| Model | Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100S |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø63 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G3/8 |
| Rod thread | M18×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø63mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 1402 N | 1402 N |
| 0.7 MPa | 1962 N | 1962 N |
| Max (@1.0 MPa) | 286 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100S
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 63 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100S Is Used
Transfer Line Diverter
Fine-tune the 1000 mm extend stop on-site to match varying pallet sizes without changing the cylinder mount, ensuring precise routing on the conveyor.
Long-Reach Press Tooling
Uses the 900 to 1000 mm extend window to dial in the exact contact point on large parts, relying on the 29 mm cushions to stop the load safely.
Is the Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100S the Right Cylinder?
The adjustable stroke is ideal when you need to fine-tune the extend end position on-site without swapping the cylinder, or when consolidating spare parts across slightly different stroke variants. Mounting options include FA, LB, TC, TCM1, and TCM2 brackets. Because the stroke is 1000 mm, you must use external guides to prevent rod bending and manage side loads. The -S magnet enables position sensing.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ63~80 Adjustable Cylinder JSIJ63X1000-100S FAQ
The theoretical maximum force is 318 kgf at 1.0 MPa. The air port size is G3/8.
The nominal 1000 mm stroke is the maximum. An external stop screw lets you shorten the extend stroke on-site by up to 100 mm, giving a usable extend range of 900 to 1000 mm. The retract end is fixed. This stop sets the end position but does not hold the load on air loss; for load holding you need an external rod lock or pilot-operated check valve.
