Airtac LGC Series Cross Roller Guide Rail LGC1B70R19-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC1B70R19-H Crossed Roller Guide Specifications
- Model: LGC1B70R19-H
- Type: Crossed roller linear guide with integrated rail
- Rail width: 70mm
- Effective stroke: 190mm (standard)
- Roller diameter: φ4.762mm (3/16")
- Dynamic load capacity: 12.5kN
- Static load capacity: 24.5kN
- Precision grade: C (High)
- Repeat positioning accuracy: ±0.005mm
- Operating temperature: -10℃ to 80℃
- Material: Bearing steel (SUJ2 equivalent) with black oxide coating
- Sealing: Triple labyrinth seal with grease retention
- Lubrication: Pre-lubricated with lithium complex grease
- Mounting hole pattern: 60mm × 60mm grid (M6 threaded holes)
- Weight: ~5.8kg (complete assembly)
- Dimensions: 700mm(L) × 70mm(W) × 19mm(H) (rail section)
High-precision crossed roller guide system featuring ultra-compact profile and zero-backlash operation. The staggered 90° roller arrangement provides multi-directional load capacity (radial, reverse radial, and lateral). Includes hardened raceways with corrosion-resistant treatment for extended service life in harsh environments.
- CNC rotary table indexing mechanisms
- Precision optical alignment stages
- Semiconductor wafer handling robots
- Coordinate measuring machine (CMM) Z-axis guides
- High-speed pick-and-place unit vertical actuators
Installation note:
Requires mounting surface flatness ≤0.01mm/m. Use torque wrench (recommended 4.9N·m for M6 bolts)
in crisscross tightening sequence. Avoid horizontal mounting without additional support blocks.
| Property | Property Value |
|---|---|
| sku | LGC1B70R19-H |
| Roller Outer Diameter | 1.5mm |
| Type | Four-Row Type |
