Airtac LRM Miniature Linear Guide LRM12L1X120S10AH
2. Anti-drop ball bearing retention mechanism for simplified installation and replacement
3. Japanese-manufactured steel balls ensuring superior sphericity and wear resistance (ISO3290 G10 compliant)
4. Enhanced oil-scraping wipers and upgraded dust-proof sealing system
5. Streamlined profile with concealed fasteners protecting sealing strips and eliminating large particulate contamination
Category: Linear Guides | Brand: AirTAC | Series: LRM
AirTAC LRM12L1X120S10AH Miniature Linear Guide Specifications
- Full model code: LRM12L1X120S10AH
- Series: LRM (Low-profile Rail Miniature)
- Rail width: 12mm
- Carriage type: Single block L1 configuration
- Effective stroke: 120mm (±0.5mm tolerance)
- Preload class: S10AH (Medium-high preload for enhanced rigidity)
- Accuracy grade: Normal grade (C) with ±15μm/100mm running parallelism
- Dynamic load capacity (C): 1,250N
- Static load capacity (C0): 2,450N
- Material: Carbon steel with black oxide coating (rail), hardened steel balls
- Sealing: Triple labyrinth seal with stainless steel scrapers
- Mounting hole pattern: 24mm × 14mm (horizontal × vertical)
- Temperature range: -20℃ to 80℃ (continuous operation)
- Lubrication: Pre-packed grease (relubrication interval: 1,000km travel)
- Weight: 0.45kg (complete assembly)
- Dimensions: 160mm(L) × 24mm(W) × 15mm(H) (rail length includes end machining)
- Protection rating: IP54 (standard seals), IP58 optional
Ultra-compact linear motion solution featuring optimized ball recirculation design for smooth operation in constrained spaces. The hardened raceway and precision-ground surfaces ensure consistent performance in high-cycle applications. Requires mounting on machined reference surfaces (recommended flatness ≤0.01mm/mm).
- Medical device positioning stages
- 3D printer X/Y axis mechanisms
- Laboratory automation slide systems
- Semiconductor wafer inspection equipment
- Precision optical alignment devices
Installation tip:
Use torque-controlled tightening (0.8-1.2Nm) for M3 mounting screws and
perform parallel alignment verification with 0.02mm/m tolerance gauge.
Avoid lateral impact during
installation - use protective covers until final assembly. Compatible with
ISO 32-68 hydraulic oil environments but requires additional wipers for
particulate contamination zones.
| Property | Property Value |
|---|---|
| sku | LRM12L1X120S10AH |
| Slide Rail Width | 12mm |
