Airtac LRM Miniature Linear Guide LRM12L1X120S10APT
2. Anti-drop ball bearing retention mechanism for simplified installation and replacement
3. Japanese-manufactured steel balls ensuring superior sphericity and wear resistance (ISO3290 G10 compliant)
4. Enhanced oil-scraping wipers and upgraded dust-proof sealing system
5. Streamlined profile with concealed fasteners protecting sealing strips and eliminating large particulate contamination
Category: Linear Guides | Brand: AirTAC | Series: LRM
AirTAC LRM Micro Linear Guide LRM12L1X120S10APT Technical Specifications
- Model: LRM12L1X120S10APT
- Series: Micro Linear Motion Guide
- Rail width: 12mm
- Total length: 120mm (±0.1mm tolerance)
- Block length: 34mm
- Ball diameter: 1.588mm (1/16")
- Dynamic load rating (C): 1,260N
- Static load rating (C0): 610N
- Preload level: APT (Medium preload: 3-5% of C)
- Accuracy grade: Normal grade (≤50μm/300mm)
- Material: Carbon steel with chrome plating (HRC58-62)
- Sealing: Triple labyrinth seal + stainless steel scrapers
- Weight: 0.28kg (rail only), 0.15kg (slider)
- Dimensions: 120mm(L) × 12mm(W) × 19.5mm(H)
- Mounting hole spacing: 60mm (center-to-center)
- Operating temperature: -20℃ to 80℃
- Lubrication: Grease-packed (Relubrication interval: 1,000km)
Ultra-compact linear motion system combining high rigidity with minimal space requirements. Features corrosion-resistant hardened steel construction and multi-stage sealing for contaminated environments. The APT preload version delivers optimal balance between smooth motion and vibration damping.
- Precision laboratory automation stages
- 3D printer X/Y axis mechanisms
- Medical device positioning systems
- Semiconductor wafer handling robots
- Compact CNC engraving machines
- Optical inspection equipment slides
Installation guidance:
Ensure mounting surface flatness ≤0.02mm/m. Use 1.2-1.5N·m torque for M4 mounting screws.
For vertical installations, position slider below rail to prevent particulate accumulation.
| Property | Property Value |
|---|---|
| sku | LRM12L1X120S10APT |
| Slide Rail Width | 12mm |
