Airtac LRM Miniature Linear Guide LRM12L1X140S7.5AH
2. Anti-drop ball bearing retention mechanism for simplified installation and replacement
3. Japanese-manufactured steel balls ensuring superior sphericity and wear resistance (ISO3290 G10 compliant)
4. Enhanced oil-scraping wipers and upgraded dust-proof sealing system
5. Streamlined profile with concealed fasteners protecting sealing strips and eliminating large particulate contamination
Category: Linear Guides | Brand: AirTAC | Series: LRM
AirTAC LRM12L1X140S7.5AH Miniature Linear Guide Specifications
- Model: LRM12L1X140S7.5AH
- Type: Compact recirculating ball linear guide system
- Rail width: 12mm
- Carriage quantity: Single block (L1 designation)
- Effective stroke: 140mm (±0.5mm tolerance)
- Accuracy grade: Normal class (N) with 7.5μm height tolerance (H)
- Dynamic load capacity (C): 1,250N
- Static load capacity (C0): 2,450N
- Material: Carbon steel with black electroless nickel plating
- Sealing: Triple-lip contact seals + stainless steel scrapers
- Temperature range: -20℃ to 80℃
- Pre-lubrication: Lithium soap grease (relubrication interval: 1,000km)
- Mounting hole spacing: 40mm longitudinal pitch (M4 threaded holes)
- Weight: 0.82kg (complete assembly)
- Dimensions: 200mm(L) × 28mm(W) × 15.5mm(H)
Ultra-slim linear motion solution combining high rigidity with minimal installation space. Features staggered ball circuit design for smooth operation (≤25dB noise level) and anti-creep preload adjustment. Compatible with ISO 10285-1 standard, requires alignment within 0.05mm/m parallelism tolerance during installation.
- Medical imaging equipment sliding mechanisms
- PCB laser marking machine XY stages
- Desktop CNC router axis guidance
- Automated microscope slide handlers
- Semiconductor wafer inspection systems
Installation note:
Use 0.02mm feeler gauge to verify rail straightness before mounting.
Apply 2.5-3.5N·m torque for M4 mounting screws with Loctite 243 threadlocker.
| Property | Property Value |
|---|---|
| sku | LRM12L1X140S7.5AH |
| Slide Rail Width | 12mm |
