Airtac LRM Miniature Linear Guide LRM12L1X145S10APT
2. Anti-drop ball bearing retention mechanism for simplified installation and replacement
3. Japanese-manufactured steel balls ensuring superior sphericity and wear resistance (ISO3290 G10 compliant)
4. Enhanced oil-scraping wipers and upgraded dust-proof sealing system
5. Streamlined profile with concealed fasteners protecting sealing strips and eliminating large particulate contamination
Category: Linear Guides | Brand: AirTAC | Series: LRM
AirTAC LRM12L1X145S10APT Miniature Linear Guide Specifications
- Model: LRM12L1X145S10APT
- Series: LRM ultra-compact series
- Rail width: 12mm
- Total length: 145mm (effective stroke customizable)
- Carriage length: 34mm
- Preload level: Light preload (L1 class)
- Load capacity:
- Dynamic: 1.3kN (C)
- Static: 2.1kN (C0)
- Moment load: 18Nm (MR)
- Accuracy grade: Normal grade (N)
- Sealing: Dual wiper system (S10 dustproof)
- Lubrication: Pre-lubed with AKT grease (APT suffix)
- Material:
- Rail: Stainless steel GCr15
- Carriage: Aluminum alloy with hardened steel balls
- Weight: 480g ±2% (full assembly)
- Dimensions:
- Rail: 145mm(L) × 12mm(W) × 9.5mm(H)
- Carriage: 34mm(L) × 24mm(W) × 15.2mm(H)
- Operating temperature: -10℃ to 80℃
- Surface roughness: Ra 0.8μm (rolling contact surfaces)
Ultra-slim linear motion solution combining high rigidity with minimal space requirements. Features precision-ground raceways and 4-row circular arc groove design for smooth motion consistency. The S10 sealing system integrates front metal scraper and rear rubber seal for particle exclusion in ISO Class 4 environments.
- High-speed PCB component placement machines
- Medical analyzers requiring vibration-free motion
- Semiconductor wafer inspection stages
- Cleanroom-compatible automation equipment
- Precision optical alignment systems
Mounting guidance:
Ensure rail parallelism ≤0.02mm/m using precision level. Use M3×6mm screws at
120mm pitch (max 0.5Nm torque). Relubricate every 500km travel with AKT-2 grease.
| Property | Property Value |
|---|---|
| sku | LRM12L1X145S10APT |
| Slide Rail Width | 12mm |
