Airtac LRM Miniature Linear Guide LRM12L1X145S10BPT
2. Anti-drop ball bearing retention mechanism for simplified installation and replacement
3. Japanese-manufactured steel balls ensuring superior sphericity and wear resistance (ISO3290 G10 compliant)
4. Enhanced oil-scraping wipers and upgraded dust-proof sealing system
5. Streamlined profile with concealed fasteners protecting sealing strips and eliminating large particulate contamination
Category: Linear Guides | Brand: AirTAC | Series: LRM
AirTAC LRM12L1X145S10BPT Miniature Linear Guide Specifications
- Model: LRM12L1X145S10BPT
- Type: Compact recirculating ball linear guide system
- Rail width: 12mm
- Carriage quantity: Single block (L1 designation)
- Stroke length: 145mm ±0.2mm
- Accuracy grade: C10 (high precision)
- Dynamic load capacity: 1.2kN (radial), 0.6kN (reverse)
- Static load capacity: 3.5kN (radial), 1.8kN (reverse)
- Preload level: Medium (PT suffix)
- Repeat positioning accuracy: ±0.003mm
- Operating temperature: -20℃ to 80℃
- Sealing: Triple labyrinth seal with grease retention
- Material: Bearing steel (hardened to HRC 58-62) with black oxide coating
- Weight: 310g ±5% (complete assembly)
- Dimensions: 205mm(L) × 24mm(W) × 15mm(H) (rail length includes carriage)
Ultra-compact linear motion solution featuring optimized ball circuit design for smooth operation under medium loads. The hardened steel construction with multi-stage sealing ensures long-term reliability in contaminated environments. Preloaded balls eliminate mechanical play while maintaining low friction coefficient (μ<0.003).
- Precision medical device positioning stages
- Laboratory automation slide mechanisms
- 3D printer X/Y axis guidance systems
- Semiconductor wafer handling equipment
- Optical lens adjustment assemblies
- Miniature robotic arm joints
Installation note:
Requires mounting surface flatness <0.01mm/m. Use M3×6mm flat head screws at
≤50mm intervals. Apply lithium complex grease (ISO VG 10-15) during assembly.
Avoid side load exceeding 20% of radial capacity.
| Property | Property Value |
|---|---|
| sku | LRM12L1X145S10BPT |
| Slide Rail Width | 12mm |
