Airtac LSH Linear Guide Rail LSH15BK-F1N-H-C-M4
2. High Rigidity Four-Directional Equal Load Design: Incorporates 4-row ball circuits with 45° contact angle configuration, achieving optimal two-point contact for bidirectional radial/lateral load capacity. Optional preload application enhances system rigidity when required.
3. Interchangeability: Stringent manufacturing precision ensures dimensional consistency within stable tolerances. Integrated retainer design prevents ball dislodgement, enabling between and matching guideways while preserving operational smoothness, preload integrity, and motion accuracy.
Category: Linear Guides | Brand: AIRTAC | Series: LSH
AirTAC LSH15BK-F1N-H-C-M4 Linear Guide Rail Specifications
- Model: LSH15BK-F1N-H-C-M4
- Series: LSH Miniature Linear Guide
- Rail Width: 15mm
- Block Length: 45mm
- Preload Level: F1N (Medium Preload)
- Accuracy Grade: H (High Precision ±50μm/m)
- Sealing: Double-sided wiper + End seals (C-type)
- Ball Circuit: 4-Row Circular Arc Groove Design
- Dynamic Load Capacity (C): 1.8 kN
- Static Load Capacity (C0): 3.2 kN
- Mounting Hole Pattern: M4 screws @ 30mm pitch
- Material: Carbon Steel (SCM440) with Black Oxide Coating
- Operating Temperature: -20°C to 100°C
- Protection Rating: IP54 (Dust Protected & Splash Resistant)
- Weight per Unit:
- Rail: 0.55 kg/m
- Block: 0.18 kg
- Dimensions (Block):
- Height: 15mm
- Width: 24.5mm
- Length: 45mm
- Standard Rail Length Options: 500mm, 1000mm, 1500mm (Customizable)
A compact linear motion solution combining high rigidity with smooth operation. Features optimized ball recirculation for low noise (<55dB) and maintenance-free operation. The black oxide coating enhances corrosion resistance in humid environments. Compatible with automatic lubrication systems through grease nipple ports.
- High-speed CNC tool changers
- Precision 3D printer X/Y axis systems
- Semiconductor wafer handling robots
- Medical imaging equipment sliding mechanisms
- Automated optical inspection (AOI) machines
Installation Tip:
Use alignment jigs during mounting to ensure parallel tolerance <0.02mm/m.
Apply Loctite 243 to mounting screws and torque to 1.2N·m.
Run-in with ISO VG32 grease for 50 cycles before full-load operation.
| Property | Property Value |
|---|---|
| sku | LSH15BK-F1N-H-C-M4 |
| Slider Width | <15mm> |
| Slide Block Type | Flange Locking Style |
