Airtac LSH Linear Guide Rail LSH15BK-F2N-N-B-M4
$43.02
Regular price
$50.52
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
LSH15BK-F2N-N-B-M4
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Self-aligning Capability: Features front-mounted X-type (45°×45°) arc raceway groove design with automatic alignment compensation. The internal mechanism absorbs minor mounting surface deviations to maintain high-precision, smooth, and stable linear motion.
2. High Rigidity Four-Directional Equal Load Design: Incorporates 4-row ball circuits with 45° contact angle configuration, achieving optimal two-point contact for bidirectional radial/lateral load capacity. Optional preload application enhances system rigidity when required.
3. Interchangeability: Stringent manufacturing precision ensures dimensional consistency within stable tolerances. Integrated retainer design prevents ball dislodgement, enabling between and matching guideways while preserving operational smoothness, preload integrity, and motion accuracy.
Category: Linear Guides | Brand: AIRTAC | Series: LSH
Installation note:
Use torque-controlled tightening (0.7-0.9Nm for M4 screws) and align rails within 0.05mm/m straightness tolerance.
Apply thread locker on mounting screws for vibration-prone environments.
2. High Rigidity Four-Directional Equal Load Design: Incorporates 4-row ball circuits with 45° contact angle configuration, achieving optimal two-point contact for bidirectional radial/lateral load capacity. Optional preload application enhances system rigidity when required.
3. Interchangeability: Stringent manufacturing precision ensures dimensional consistency within stable tolerances. Integrated retainer design prevents ball dislodgement, enabling between and matching guideways while preserving operational smoothness, preload integrity, and motion accuracy.
Category: Linear Guides | Brand: AIRTAC | Series: LSH
AirTAC LSH15BK-F2N-N-B-M4 Linear Guide Rail Specifications
- Model: LSH15BK-F2N-N-B-M4
- Series: LSH Miniature Linear Guide
- Rail type: Ball-type linear guide with 4-row circular groove design
- Nominal size: 15mm (rail width)
- Block length: 54mm (standard)
- Dynamic load capacity (C): 6.3kN
- Static load capacity (C0): 9.8kN
- Precision grade: Normal grade (N) with ±50μm/m accuracy
- Preload level: F2 (Medium preload: 5-8% of C)
- Sealing system: Triple labyrinth seal with stainless steel scrapers
- Rail material: Carbon steel with black oxide coating (BK)
- Block material: Hardened carbon steel
- Mounting hole pattern: M4 screws with 30mm spacing
- Operating temperature: -20℃ to 100℃
- Protection rating: IP54 (standard sealing)
- Weight per unit: 1.2kg/m (rail), 0.28kg (block)
- Dimensions:
- Rail height: 15mm
- Rail width: 24mm
- Block dimensions: 54mm(L) × 24mm(W) × 15mm(H)
- Lubrication: Pre-lubricated with AFT-1D grease
High-rigidity miniature guide system featuring optimized ball circulation for smooth motion and vibration damping. The BK-coated rail provides enhanced corrosion resistance in humid environments. Designed for space-constrained applications requiring precise linear motion with moderate load capacity.
Typical Applications:
- CNC machine tool Z-axis positioning
- Automated optical inspection (AOI) equipment
- 3D printer gantry systems
- Semiconductor wafer handling robots
- Medical device assembly lines
Installation note:
Use torque-controlled tightening (0.7-0.9Nm for M4 screws) and align rails within 0.05mm/m straightness tolerance.
Apply thread locker on mounting screws for vibration-prone environments.
Compatible accessories:
- LSH15 carriage blocks with different preload options (F0/F1/F2)
- End seals: ERS-15 dust covers
- Alignment tools: AGT-15L laser alignment jig
| Property | Property Value |
|---|---|
| sku | LSH15BK-F2N-N-B-M4 |
| Slider Width | <15mm> |
| Slide Block Type | Flange Type Bottom Lock Style |
