Airtac LSH Linear Guide Rail LSH15BK-HN-N-C-M4
2. High Rigidity Four-Directional Equal Load Design: Incorporates 4-row ball circuits with 45° contact angle configuration, achieving optimal two-point contact for bidirectional radial/lateral load capacity. Optional preload application enhances system rigidity when required.
3. Interchangeability: Stringent manufacturing precision ensures dimensional consistency within stable tolerances. Integrated retainer design prevents ball dislodgement, enabling between and matching guideways while preserving operational smoothness, preload integrity, and motion accuracy.
Category: Linear Guides | Brand: AIRTAC | Series: LSH
AirTAC LSH15BK-HN-N-C-M4 Linear Guide Rail Specifications
- Model: LSH15BK-HN-N-C-M4
- Series: LSH (Micro-Line Compact Series)
- Rail width: 15mm
- Block type: BK (Standard Flange, Narrow Type)
- Preload class: HN (Medium Preload)
- Rail length: N (Standard length 500mm, customizable up to 4000mm)
- Accuracy grade: C (High Precision ±5μm/100mm)
- Mounting hole: M4 (4mm screw diameter)
- Dynamic load capacity: 2.1 kN
- Static load capacity: 3.2 kN
- Ball diameter: 2.381mm
- Recirculation system: 4-Row Circular Arc Groove Design
- Sealing: Triple-lip contact seals + End scrapers
- Material: Carbon steel (GCR15 bearing steel) with black oxide coating
- Operating temperature: -10℃ to 80℃
- Protection rating: IP54 (Dust protected & water splashed)
- Weight per unit:
- Block: 0.28 kg
- 500mm rail: 0.65 kg
- Dimensions:
- Block: 60mm(L) × 24mm(W) × 15mm(H)
- Rail profile: 15mm(W) × 12mm(H)
Ultra-compact linear motion solution with optimized load distribution, featuring hardened raceways (HRC 58-62) for extended service life. The HN preload ensures minimal deflection during high-speed reciprocation (up to 5m/s). Integrated sealing system retains grease lubrication for 10,000+ km travel life.
- Precision CNC tool changers & spindle drives
- Semiconductor wafer handling robots
- 3D printer X/Y axis motion systems
- Medical imaging equipment sliding mechanisms
- Automated optical inspection (AOI) stages
Installation guidelines:
Use torque-controlled wrench (0.7-0.9Nm for M4 screws) with parallel mounting
sequence. Maintain 0.02mm/m straightness tolerance during rail alignment.
Apply ISO VG15-32 grease through zerk fittings every 500 operating hours.
| Property | Property Value |
|---|---|
| sku | LSH15BK-HN-N-C-M4 |
| Slider Width | <15mm> |
| Slide Block Type | Square Body |
