Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X100-CA
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X100-CA Aluminum Miniature Cylinder Specifications
- Model: MAL20X100-CA
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 100mm
- Operating pressure: 0.15–0.8 MPa
- Port size: M5x0.8 (standard), optional NPT1/8
- Cushioning: Adjustable rubber buffer
- Temperature range: -10℃ to 80℃
- Mounting type: CA series (front flange with tapped holes)
- Weight: 280g ±5g
- Dimensions:
- Extended length: 160mm
- Retracted length: 60mm
- Body diameter: 32mm
- Mounting flange: 50mm x 20mm
- Seal material: NBR (Nitrile rubber)
- Rod material: Stainless steel (SUS304)
- Protection rating: IP54 (standard wiper design)
- Lubrication: Pre-lubricated (Grease G-46)
Ultra-compact aluminum cylinder optimized for space-constrained automation systems. Features precision-machined guide grooves for stable linear motion and anodized surface treatment for corrosion resistance. The double-seal structure prevents leakage in low-pressure applications (＜0.2 MPa). Requires 5μm filtered air with ISO 8573-1:2010 Class 3 purity standards.
- PCB handling robots in electronics assembly
- Precision clamping devices for CNC tooling
- Medical device actuators requiring smooth motion
- Food packaging machine ejectors (FDA-compliant grease option available)
- Laboratory automation positioning stages
Installation note:
For vertical mounting, reduce operating pressure by 15% to compensate for spring force.
Maintain 0.5mm minimum clearance between rod end and workpiece. Lubricate every 500,000 cycles
using AirTAC PG-10 grease.
| Property | Property Value |
|---|---|
| sku | MAL20X100-CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
