Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X100-CM
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X100-CM Aluminum Miniature Cylinder Technical Details
- Series: MAL20 Aluminum Mini Cylinder
- Bore size: 20mm
- Stroke: 100mm
- Action type: Double-acting
- Material: Aluminum alloy body/chrome-plated steel piston rod
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Cushioning: Adjustable rubber buffers (both ends)
- Mounting style: Basic type (optional foot/mounting flange available)
- Port size: M5 (Rc1/8 adapter optional)
- Operating temperature: -20℃ to +80℃
- Piston speed: 50–800 mm/s
- Weight: 0.45 kg (0.99 lbs)
- Dimensions: 135mm(L) × 25mm(W) × 25mm(H)
- Seal material: NBR (Nitrile rubber)
- Rod thread: M6×1.0 (external)
- Protection class: IP54 (standard wiper design)
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features precision honed aluminum barrel with oxidation-resistant coating and low-friction seals. The chrome-plated piston rod withstands side loads up to 1.5N·m. Requires ISO 8573-1:2010 Class 3 lubricated or non-lubricated air.
- PCB handling robots in electronics manufacturing
- Dispenser valve actuation in medical devices
- Label applicators in packaging lines
- Precision clamping fixtures for CNC loading
- Vending machine mechanisms
Installation tip:
For vertical mounting, add 10% extra stroke capacity to compensate for
gravitational sag. Lubricate through air port monthly in high-cycle
applications (＞500,000 cycles/year).
| Property | Property Value |
|---|---|
| sku | MAL20X100-CM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
