Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X100-CM-LB
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X100-CM-LB Aluminum Miniature Cylinder Specifications
- Model: MAL20X100-CM-LB
- Bore size: 20mm
- Stroke: 100mm
- Construction: Anodized aluminum alloy body (hard coating oxidation treatment)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting type: Front flange with 4×M5 threaded holes (30mm square pattern)
- Piston rod thread: M10×1.25
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to +80℃
- Air lubrication: Required (ISO 8573-1 class 3 or cleaner)
- Weight: 0.62kg
- Dimensions: 160mm(L) × 34mm(W) × 34mm(H)
- Rod end type: Female thread + hex nut
- Protection rating: IP40 (standard), IP67 optional
- Max theoretical force (@0.63MPa): 198N (extend), 168N (retract)
Ultra-compact linear actuator combining lightweight aluminum construction with precision machining. Features integrated magnet for position sensing compatibility (inductive sensors) and corrosion-resistant surface treatment. The double-acting design ensures stable bidirectional operation, with 0.5mm/s minimum speed capability for delicate movements.
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging machines
- Automated optical inspection (AOI) equipment
- Precision dosing valve actuators
- Textile machinery thread guides
- Laboratory automation sample handlers
Installation notes:
Maintain 0.5-1mm clearance between cylinder body and mounting surface for thermal expansion.
Use Loctite 243 on mounting screws (3.5Nm max torque). Lubricate through air port with ISO VG32
turbine oil before initial operation. Magnetic sensor cables must maintain 10cm separation
from power lines to prevent signal interference.
| Property | Property Value |
|---|---|
| sku | MAL20X100-CM-LB |
| Rear Cover Type | Round Type |
| Mounting Type | Axial Mounting Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
