Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X25-CM
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X25-CM Aluminum Miniature Cylinder Specifications
- Model: MAL20X25-CM
- Bore size: 20mm
- Stroke: 25mm (±1mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Port thread: M5×0.8 (standard) / NPT1/8 (optional)
- Piston speed: 50–700 mm/s
- Cushioning: Adjustable rubber buffer
- Material: Aluminum alloy body (A6063-T5) + CRMO steel piston rod
- Seal type: NBR (standard) / FKM (high temp option)
- Weight: 230g ±5g (without accessories)
- Dimensions:
- Extended length: 107mm
- Retracted length: 82mm
- Body width: 34mm
- Mounting hole spacing: 15mm (front) / 25mm (rear)
- ISO standard: 6432 compliant
- Protection rating: IP54 (standard) / IP67 (w/ optional rod cover)
Ultra-compact pneumatic cylinder featuring precision-machined aluminum construction with hard anodized surface treatment. The dual-piston design ensures smooth linear motion and high lateral load capacity (up to 15N). Integrated magnetic slot allows for position sensing compatibility. Corrosion-resistant with PTFE-coated rod for dry environments.
- PCB handling robots in electronics manufacturing
- Dispenser nozzle actuation in packaging lines
- Micro-positioning in optical lens assembly
- Medical analyzer sample tray movement
- Semiconductor wafer cassette elevators
Installation best practices:
Use locknuts (M5×0.8) with 0.5-1.5Nm torque for mounting.
Lubricate with ISO VG32 hydraulic oil if operating below 0.3 MPa.
Allow 3mm clearance around magnetic sensor slots.
| Property | Property Value |
|---|---|
| sku | MAL20X25-CM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <25 mm> |
