Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X25-U-FA
$25.55
Regular price
$33.05
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MAL20X25-U-FA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AIRTRAC MAL20 Aluminum Miniature Cylinder Features:
1. Engineered with precision using high-grade aluminum alloy round tube barrel construction;
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
Installation guidelines:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use counterbalance valves. Lubricate every 6 months
under normal operation (2000 cycles/day).
Avoid side load exceeding 5N.
Maximum permissible lateral play: ±0.3mm. Install guide mechanisms
when lateral forces exceed 2N.
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X25-U-FA Aluminum Miniature Cylinder Specifications
- Full model: MAL20X25-U-FA
- Series: MAL Aluminum Mini Cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 25mm (adjustable cushion range ±2mm)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Cushion type: Elastic rubber + adjustable buffer
- Mounting style: U-type foot with through holes
- Body material: 6063-T5 aluminum alloy
- Rod material: Stainless steel (SUS304)
- Seal material: Polyurethane (NBR optional)
- Weight: 0.18kg (excluding accessories)
- Dimensions:
- Total length: 123mm (at full extension)
- Body width: 34mm (mounting foot span)
- Height: 28mm (excluding piston rod protrusion)
- ISO standard: Compliant with ISO 6432 (mounting dimensions)
- Lubrication: Pre-lubricated (Use ISO VG32 hydraulic oil)
Ultra-compact pneumatic cylinder featuring anodized corrosion-resistant construction and dual cushioning system. The U-shaped mounting base allows secure fixation in space-constrained environments. Optimized for high-speed applications (≤1.5m/s) with a 0.5mm/s² shock absorption design. Requires 5μm filtered air with ≤40% relative humidity.
Ideal Applications:
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in CNC tool changers
- Valve actuation in medical analyzers
- Labeling machine pusher mechanisms
- Automated packaging line diverters
Installation guidelines:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use counterbalance valves. Lubricate every 6 months
under normal operation (2000 cycles/day).
Avoid side load exceeding 5N.
Maximum permissible lateral play: ±0.3mm. Install guide mechanisms
when lateral forces exceed 2N.
| Property | Property Value |
|---|---|
| sku | MAL20X25-U-FA |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Front Flange Mounting Plate |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <25 mm> |
