Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X250-S-CA
$32.27
Regular price
$39.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MAL20X250-S-CA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AIRTRAC MAL20 Aluminum Miniature Cylinder Features:
1. Engineered with precision using high-grade aluminum alloy round tube barrel construction;
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
Installation tip:
For vertical mounting exceeding 45° inclination, use MALSX series brackets.
Apply light machine oil (ISO VG32) monthly in high-cycle applications (>500k cycles/year).
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X250-S-CA Aluminum Miniature Cylinder Specifications
- Model: MAL20X250-S-CA
- Type: Double-acting compact cylinder with magnetic piston
- Bore size: 20 mm
- Stroke: 250 mm (±1.5mm tolerance)
- Material: Anodized aluminum alloy (body), CR12MoV steel (piston rod)
- Mounting style: CA series - front flange with mounting holes (M5×0.8)
- Port size: M5×0.8 (G1/8 adapter optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Cushioning: Adjustable rubber buffer (both ends)
- Temperature range: -20℃ to 80℃ (non-freezing)
- Seal material: High-grade NBR (nitrile rubber)
- Protection rating: IP65 (standard wiper design)
- Weight: 1.2 kg (with rod, without accessories)
- Dimensions: 300mm(L) × 50mm(W) × 50mm(H) (at full extension)
- Max speed: 500 mm/s (with cushioning)
- Lubrication: Pre-lubricated (DOP mist compatible)
Ultra-slim profile cylinder optimized for confined spaces, featuring enhanced side load resistance through integrated guide grooves. The chrome-plated piston rod resists corrosion in humid environments. Includes built-in magnet for position sensing compatibility with S-08 series sensors (sold separately).
Ideal Applications:
- PCB handling robots in electronics manufacturing
- Precision clamping devices for CNC tooling
- Automated cosmetic dispensing systems
- Compact packaging machine actuators
- Laboratory sample sorting mechanisms
Installation tip:
For vertical mounting exceeding 45° inclination, use MALSX series brackets.
Apply light machine oil (ISO VG32) monthly in high-cycle applications (>500k cycles/year).
| Property | Property Value |
|---|---|
| sku | MAL20X250-S-CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <250MM> → <250mm> |
