Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X250-S-CM
$32.27
Regular price
$39.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MAL20X250-S-CM
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AIRTRAC MAL20 Aluminum Miniature Cylinder Features:
1. Engineered with precision using high-grade aluminum alloy round tube barrel construction;
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
Installation guidelines:
Maintain ≤0.5mm alignment tolerance during mounting. Lubricate rod weekly in high-cycle applications (>500k cycles/year). Use SMC-LUBE II or equivalent grease.
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X250-S-CM Aluminum Miniature Cylinder Specifications
- Model: MAL20X250-S-CM
- Type: Single-acting spring return (compact series)
- Bore size: 20mm
- Stroke: 250mm (±1.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Mounting style: Compact male thread (M10×1.25)
- Port size: M5×0.8 (G1/8 adaptor included)
- Material: Anodized aluminum body, NBR seals
- Weight: 580g ±3% (without accessories)
- Dimensions:
- Length: 305mm (fully extended)
- Body diameter: 32mm
- Mounting base: 20mm×20mm square profile
- Piston rod: Chrome-plated steel (Ø6mm)
- Max theoretical force: 31.4N @ 0.5MPa
- ISO standard: 6432 compliant
Ultra-slim pneumatic cylinder optimized for space-constrained automation systems. Features anti-rotation piston rod design and corrosion-resistant construction. Includes built-in magnet for magnetic sensor compatibility (D-M9 series). Requires 5μm filtered air with ISO VG32 lubricant.
Typical Applications:
- PCB handling robots in electronics manufacturing
- Pharmaceutical blister packaging machines
- Automated microscope stage positioning
- Textile cutting equipment actuators
- Semiconductor wafer cassette elevators
Installation guidelines:
Maintain ≤0.5mm alignment tolerance during mounting. Lubricate rod weekly in high-cycle applications (>500k cycles/year). Use SMC-LUBE II or equivalent grease.
| Property | Property Value |
|---|---|
| sku | MAL20X250-S-CM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <250MM> → <250mm> |
