Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X400-CA
$34.34
Regular price
$41.84
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MAL20X400-CA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AIRTRAC MAL20 Aluminum Miniature Cylinder Features:
1. Engineered with precision using high-grade aluminum alloy round tube barrel construction;
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
Installation tip:
Maintain 0.5-1mm clearance between rod end and load during alignment.
For vertical mounting, use speed controller (ASC-06) to prevent piston slam.
Relubricate every 500km of cumulative travel distance.
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X400-CA Aluminum Mini Cylinder Specifications
- Model: MAL20X400-CA
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 400mm
- Operating pressure: 0.05-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Mounting: Basic foot mounting (ISO 6432 standard)
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Piston rod thread: M6x1.0
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Weight: 1.25kg ±3%
- Dimensions: 440mm(L) x 32mm(W) x 32mm(H)
- Protection rating: IP54
- Lubrication: Pre-lubricated (DOP mist compatible)
Ultra-slim profile cylinder with extended stroke capability, featuring precision-machined guide bearings for reduced side load wear. The anodized surface treatment enhances corrosion resistance in humid environments. Requires 5-40μm filtered compressed air with ≤5mg/m³ oil content.
Typical Applications:
- High-density automation tool changers
- Semiconductor wafer handling systems
- Textile machinery thread tension control
- Vertical packaging machine sealing bars
- 3D printer filament feed mechanisms
Installation tip:
Maintain 0.5-1mm clearance between rod end and load during alignment.
For vertical mounting, use speed controller (ASC-06) to prevent piston slam.
Relubricate every 500km of cumulative travel distance.
| Property | Property Value |
|---|---|
| sku | MAL20X400-CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <400mm> |
