Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X50-CA-H
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X50-CA-H Aluminum Miniature Cylinder Specifications
- Model: MAL20X50-CA-H
- Type: Double-acting compact cylinder
- Bore size: Ø20mm
- Stroke: 50mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Medium temperature: -20℃ to 80℃ (non-freezing)
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting style: Front flange (MF1) with rear threaded mounting (TR20×1.5)
- Port size: M5×0.8 (G1/8 adapter available)
- Seal material: Heat-resistant NBR (FDA compliant)
- Protection rating: IP40 (standard dust protection)
- Weight: 0.25kg (excluding accessories)
- Dimensions: 90mm(L) × 40mm(W) × 20mm(H) (fully retracted)
- Rod thread: M6×1.0 external thread (4mm rod diameter)
- Max theoretical force: 25.1kgf@0.5MPa (extend), 22.3kgf@0.5MPa (retract)
Ultra-compact aluminum cylinder with precision-ground stainless steel rod (hard chrome plated) for smooth operation. Features anti-rotation design with integrated guide slots and dual cushion adjustment screws. The CA-H variant includes enhanced heat-resistant seals for continuous duty cycles. Requires 5μm filtered air with ISO VG32 lubricant recommendation.
- Precision clamping in CNC tool changers
- Actuation in semiconductor wafer handling
- Medical device positioning systems
- Food packaging ejector mechanisms
- 3D printer nozzle cleaning systems
Installation note:
Maintain 0.05mm maximum misalignment during mounting. For vertical installations,
use locknut (ASNU6) to prevent thread loosening. Lubricate through air port monthly
in high-cycle applications (＞500,000 cycles/year).
| Property | Property Value |
|---|---|
| sku | MAL20X50-CA-H |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <50mm> |
