Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X50-CM
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X50-CM Aluminum Miniature Cylinder Specifications
- Model: MAL20X50-CM
- Bore size: 20mm
- Stroke: 50mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s (lubricated)
- Port size: M5x0.8 (Rc1/8/NPT1/8 optional)
- Cushioning: Rubber buffer (adjustable optional)
- Mounting type: Front flange (ISO 15552 standard)
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR/PU (oil-resistant)
- Weight: 320g ±5g (without accessories)
- Dimensions:
- Total length: 134mm (at mid-stroke)
- Body diameter: Φ32mm
- Mounting base: 25×25mm square flange
- Rod end thread: M6×1.0
- ISO certification: 6431, VDMA 24562
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features precision honed tube and dual sealing system for leak-free operation up to 1 million cycles. The CM variant includes magnetic piston for position sensing compatibility (sensors sold separately). Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
- PCB handling robots in electronics manufacturing
- Pharmaceutical blister packaging machines
- Textile machinery thread tension control
- Semiconductor wafer clamping mechanisms
- 3D printer automatic bed leveling systems
Maintenance tip:
Perform air bleeding every 500km of cumulative stroke travel.
Replace cushion seals after 2 million cycles in high-speed applications.
| Property | Property Value |
|---|---|
| sku | MAL20X50-CM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <50mm> |
