Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X600CM
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X600CM Aluminum Miniature Cylinder Specifications
- Model: MAL20X600CM
- Bore size: 20mm
- Stroke: 600mm
- Operation type: Double-acting
- Material: Aluminum alloy body, chrome-plated piston rod
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (standard), optional NPT1/8
- Piston speed: 50–800 mm/s
- Mounting type: Foot-mounted (CM series)
- Seal material: NBR (standard), optional FKM
- Protection rating: IP40
- Weight: ~1.8 kg
- Dimensions: 660mm(L) × 60mm(W) × 60mm(H)
Ultra-long stroke compact cylinder with precision-ground rod and wear-resistant seals. Features corrosion-resistant aluminum construction and integrated mounting slots for space-efficient installation. Designed for medium-load applications requiring extended linear motion in constrained spaces.
- Automated material handling systems
- Long-stroke packaging machinery actuators
- Electronics assembly positioning devices
- Medical equipment linear motion control
- Textile machinery tensioning systems
Installation note:
Ensure proper rod alignment (±0.5° angular tolerance) and use SAE VG32 hydraulic oil or ISO VG32 turbine oil for lubrication. Maintain 10% safety margin on maximum load capacity (400N thrust at 0.6MPa).
| Property | Property Value |
|---|---|
| sku | MAL20X600CM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 600mm |
