Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X75-CM
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X75-CM Aluminum Mini Cylinder Technical Details
- Model: MAL20X75-CM
- Bore size: 20mm
- Stroke: 75mm
- Action type: Double-acting
- Material: Aluminum alloy body (anodized), CRN steel rod
- Operating pressure: 0.05-1.0 MPa
- Cushion type: Adjustable rubber buffer
- Port size: M5x0.8 (standard), optional NPT1/8
- Temperature range: -20℃ to 80℃
- Piston speed: 50-800 mm/s
- Mounting type: Front flange (ISO 15552 compliant)
- Weight: 0.52 kg (with rod)
- Dimensions: 135mm(L) × 32mm(W) × 32mm(H)
- Seal material: High-grade NBR + PTFE combination
- Position detection: Built-in magnet for sensor mounting
Precision-engineered mini cylinder optimized for space-constrained automation systems. Features wear-resistant chromium-plated rod and corrosion-resistant aluminum construction. The CM variant includes magnetic field detectability for position feedback systems. Requires ISO 8573-1:2010 Class 3 lubricated or non-lubricated air.
- PCB handling robots in electronics manufacturing
- Dispenser valve actuation in packaging lines
- Medical analyzer slide mechanisms
- Precision clamping in CNC tool changers
- Automated test equipment positioning
Installation guidance:
Maintain 0.5-1mm clearance between magnetic sensor and cylinder body.
For vertical mounting, use rod-down orientation to prevent seal wear.
Lubricate through air supply (ISO VG32 recommended) for >1 million cycle lifespan.
| Property | Property Value |
|---|---|
| sku | MAL20X75-CM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 75mm |
