Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X75-S-U
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X75-S-U Aluminum Miniature Cylinder Specifications
- Model: MAL20X75-S-U
- Type: Single-acting spring return (with magnetic piston)
- Bore size: 20mm
- Stroke: 75mm
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (1/8" NPT optional)
- Cushioning: Adjustable rubber buffer
- Mounting style: U-shaped bracket with through holes
- Piston rod thread: M6x1.0
- Material: Anodized aluminum alloy (body), Chrome-plated steel (rod)
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP65
- Weight: 0.35kg ±5%
- Dimensions: 130mm(L) × 32mm(W) × 32mm(H)
Ultra-compact cylinder optimized for space-constrained automation systems. Features built-in magnet for position sensing compatibility and corrosion-resistant construction. The double-wall anodized surface provides enhanced wear resistance in humid environments. Requires 1-2 drops of ISO VG32 hydraulic oil monthly for maintenance.
- PCB handling robots in electronics assembly
- Precision valve actuation in analytical instruments
- Paper feed mechanisms in office automation equipment
- Clamping devices in micro-machining centers
- Dosing pump actuators in medical devices
Installation note:
Maintain 0.5mm minimum clearance between magnetic sensor and cylinder body.
For vertical mounting, position spring return side downward to prevent
premature wear. Maximum side load: 3N at rod end.
| Property | Property Value |
|---|---|
| sku | MAL20X75-S-U |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 75mm |
