Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X75-U
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X75-U Aluminum Miniature Cylinder Specifications
- Model: MAL20X75-U
- Type: Double-acting mini cylinder (ISO 21287 compliant)
- Bore size: Ø20mm
- Stroke: 75mm (customizable: 25-150mm)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) with G1/8 adaptor optional
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting style: Basic foot mount (MF1), with optional accessories for flange/swivel mounting
- Body material: Anodized aluminum alloy (AL6063-T5)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 350g ±5% (without accessories)
- Dimensions: 140mm(L) × 20mm(W) × 50mm(H) (at mid-stroke position)
- Protection rating: IP40 (standard), IP67 with optional wiper
- Max speed: 500mm/s (with cushioning)
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features precision-machined components with wear-resistant chrome plating on piston rod. The dual anti-rotation guide structure ensures stable linear motion, while the modular design allows easy integration with position sensors (MHL2 series compatible). Requires 5μm filtered air with ISO 8573-1:2010 Class 3 air quality.
- PCB handling robots in electronics manufacturing
- Pharmaceutical blister packaging machines
- Lens positioning in optical inspection systems
- Clamping mechanisms in CNC tool changers
- Ventilation damper actuators in medical devices
Installation tip:
For vertical mounting applications exceeding 45° inclination,
use locking nuts (ASNU-5) on piston rod threads to prevent
unintended rotation. Lubricate with ISO VG32 hydraulic oil
during maintenance cycles.
| Property | Property Value |
|---|---|
| sku | MAL20X75-U |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 75mm |
