Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X80-CA-H
$31.24
Regular price
$38.74
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MAL20X80-CA-H
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AIRTRAC MAL20 Aluminum Miniature Cylinder Features:
1. Engineered with precision using high-grade aluminum alloy round tube barrel construction;
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
Installation guidelines:
Use locknuts (M5x0.8) with 0.8–1.2Nm torque for mounting.
Maintain 0.5mm minimum clearance between rod end and load.
For vertical mounting, install rod end downward to prevent seal wear.
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X80-CA-H Aluminum Miniature Cylinder Specifications
- Full model code: MAL20X80-CA-H
- Type: Double-acting compact cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 80mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Temperature range: -20℃ to 80℃ (NBR seals)
- Cushioning: Adjustable rubber buffers (both ends)
- Mounting style: Foot-mounted (CA series)
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Material: Aluminum alloy body (anodized), CR340 piston rod
- Weight: 0.38kg (without accessories)
- Dimensions: 34mm(W) × 34mm(H) × 120mm(L) (stroke excluded)
- Piston speed: 50–700mm/s (lubricated condition)
- ISO certification: 6432/DIN ISO 15552 compliant
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features precision-machined guide bands for smooth operation and integrated mounting grooves for sensor attachment. The hard-anodized barrel resists chemical corrosion in harsh environments.
Ideal Applications:
- PCB handling robots in electronics manufacturing
- Precision clamping mechanisms in CNC tool changers
- Dispenser actuation in food packaging lines
- Valve switching in semiconductor wafer handling
- Medical device positioning systems
Installation guidelines:
Use locknuts (M5x0.8) with 0.8–1.2Nm torque for mounting.
Maintain 0.5mm minimum clearance between rod end and load.
For vertical mounting, install rod end downward to prevent seal wear.
Lubrication:
Pre-lubricated with Molykote PG-65. Relubricate every 500km stroke
using ISO VG32 turbine oil. Clean air supply (40μm filter) required.
| Property | Property Value |
|---|---|
| sku | MAL20X80-CA-H |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 80 mm |
