Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X80-CM
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X80-CM Aluminum Miniature Cylinder Specifications
- Model: MAL20X80-CM
- Bore size: 20mm
- Stroke: 80mm
- Action type: Double-acting
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Rubber buffer (adjustable both ends)
- Mounting style: MF1 (Front flange with foot mounting)
- Port size: M5×0.8 (standard) / NPT1/8 optional
- Piston rod thread: M6×1.0
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (standard) / optional FKM
- Temperature range: -20℃ to 80℃
- Weight: 320g ±5% (without accessories)
- Dimensions:
- Total length: 132mm (at mid-stroke)
- Body diameter: Φ32mm
- Mounting hole spacing: 25mm×16mm
- ISO standard: 6432 (interchangeable)
- Protection rating: IP54 (standard) / IP67 (with optional rod cover)
Ultra-compact aluminum cylinder combining lightweight construction (35% lighter than steel equivalents) with precision linear motion. Features dual anti-rotation guide slots and corrosion-resistant surfaces, optimized for high-cycle automation tasks. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.2.3 air quality.
- PCB handling robots in electronics assembly
- Lab automation sample positioning stages
- Pharmaceutical blister packaging machines
- Lens polishing equipment in optical manufacturing
- Food-grade packaging systems (with FKM seals)
Installation note:
For vertical mounting, use lock nuts on piston rod threads. Lubricate with ISO VG32 turbine oil
during maintenance. Avoid side loads exceeding 3N·m. Maximum permissible speed: 750mm/s.
| Property | Property Value |
|---|---|
| sku | MAL20X80-CM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 80 mm |
