Airtac MAL20 Aluminum Alloy Mini Cylinder MAL20X80-U
2. Thread-connected front/rear end caps ensure structural integrity and leak-proof performance;
3. Special-shaped bidirectional seal structure on piston enables compact dimensions while maintaining integrated oil reservoir functionality;
4. Self-lubricating bushing guidance system in front cap delivers superior lubrication and directional stability;
5. Multiple rear cover configurations (front thread/base mount/compact flange) enhance installation flexibility;
6. Comprehensive specifications and mounting accessories portfolio provides optimal customization options. Category: Aluminum Miniature Cylinders | Brand: AIRTAC | Series: MAL20
AirTAC MAL20X80-U Aluminum Miniature Cylinder Specifications
- Model: MAL20X80-U
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 80mm
- Material: Anodized aluminum alloy body, NBR seals
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable rubber buffer (5mm cushion length)
- Mounting style: Basic type (optional foot/axial/flange mounts)
- Port size: PT1/8 (M5x0.8 optional)
- Temperature range: -20℃ to 80℃
- Seal compatibility: Compatible with non-lubricated air (requires initial lubrication)
- Protection rating: IP40 (dust protected)
- Weight: 0.58kg (without accessories)
- Dimensions: 28mm(W) × 28mm(H) × 130mm(L) (total extended length)
- Rod thread: M6x1.0 external thread
- Max theoretical thrust: 25.1N @0.5MPa
- Mounting hole spacing: 25mm center-to-center
Ultra-compact cylinder optimized for space-constrained automation systems, featuring corrosion-resistant anodized finish and precision honed tube. The MAL series' square body design enables direct sensor mounting and prevents rotation. Requires 40μm filtered air with ISO VG32 turbine oil mist lubrication (1-2 drops/m³).
- PCB handling robots in electronics manufacturing
- Dispenser actuation in medical analyzers
- Clamping mechanisms in food packaging lines
- Valve switching in laboratory automation
- Conveyor diverters in logistics systems
Installation note:
Maintain alignment within 0.5° angular misalignment tolerance. Use rod-end bearings
for side load applications. Perform monthly lubrication checks in high-cycle
(＞5 million strokes/year) operations.
| Property | Property Value |
|---|---|
| sku | MAL20X80-U |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 80 mm |
